GBK 240 packaging machine –secure packaging for bread and baked goods
The GBK 240 automatically packs pre-made paper or plastic bags, wraps them, and seals them with a paper label. Ideal for whole loaves and sliced bread, it meets the highest cleanroom standards thanks to innovative separation of the product and drive areas.
GHD Georg Hartmann Maschinenbau GmbH
33129 Delbrück,
Germany
Technical specifications
| Dimensions: | Length: approx. 4700 mm, Width: approx. 1980 mm, Table height: approx. 960 mm, Height: min. 2200 mm |
| Weight: | 1700 kg |
| Product dimensions: | Length: 100 - 400 mm, Width: up to 260 mm, Height: 30 - 170 mm (other dimensions on request) |
| Capacity: | 2400 -2700 packs/h |
| Speed: | adjustable |
| Controller: | Omron |
| Operating panel: | Touch panel |
| Control voltage: | 24 V, DC |
| Frequency controller: | Hitachi |
| Pneumatic system: | Festo |
| Power supply: | 400 Volt / 50 Hz |
| Power consuption: | 4 kW |
| Compressed air: | min. 6,0 bar (ISO 8573-1) |
| Operating side: | left / right |
| Protection class: | IP 54 |
| Adjustment: | manual |
| Special: | Closure adhesive label with print |
